VH Powder Mixer

The VH Powder Mixer Series of machines are very easy to fill and empty. The asymmetric V shape mixing vessels are mechanically operated to produce an efficient, and highly effective uniform blend of dry powders and granules.

Main benefits at a glance

• Effectively combine dry powders of any mesh size, perfect for various capsule sizes
• Asymmetric V shaped mixing vessel avoid dead spots, ensuring proper mixing
• Keeps the nutritional or chemical capability of your products safe
• The choice of timed or continuous running with automatic cut off at the end of cycle
• Easy to clean polished 304 stainless steel vessel for sturdiness and hygiene
• Straight forward operations and controls
• Vigorous, heavy duty motor
• Condensed size, allowing for a smaller dimensional footprint
• Series offers wide range of capacities to suit any requirement
• Exceedingly effectual
• Low decibel range output

Features of the VH Powder Mixers

The VH Powder Mixers are ideal for any powders making dietary supplement capsules to animal medication capsules and everything in between. VH mixers are a simple to use and an effective solution that will allow quick mixture of dry powders or granules to the high quality demanded by today’s medical, food manufacturing and nutraceuticals high standards. The VH Powder Mixer Series are operated through an easy to read digital timer and just a few simple operating buttons. Very little training is required to operate a VH Powder Mixer.

The VH Powder mixers offer a timed, or continuous running method. This will let the operator concentrate on other tasks while the powder is being mixed. When mixing has completed and the powders or granules have been removed, cleaning is a painless process, due to the thoughtful design and hygienic, polished 304 stainless steel.

VH Powder Mixers in Use

The VH Powder Mixer Series effectively combines dry powders of any mesh size. To operate the mixer, simply open one of the top gaskets and fill the chamber approximately two thirds full. Once full, you can set a desired mixing time and press the green start button. The mixer will automatically turn off at the end of the mixing timer. Alternatively, you can set the machine to run until you manually shut it off.

Thanks to the VH Powder Mixers specially designed asymmetric V vessel and movement pattern, the mixers ensure that the powder or granules they are holding is evenly mixed within the steel mixing tubes throughout the mixing process, allowing for proper capsule doses. This gives you the reliable results that are very difficult to achieve by manual mixing. The V style blender allows no dead spots that would compromise a cohesive blend, costing more money in the long run with a poorly mixed batch.

The VH series comes in a range of sizes, each offering the perfect balance between space efficiency and capacity. The small, unobtrusive VH 8 will sit in the corner of a workshop taking up very little space, while at the far end of the range the larger, industrial sized VH 200, 300 and 500 are large manufacturing plant machines offering the capacity to cope with any sized job. What all the VH range share in common is rugged construction and reliable industrial motors, meaning that they just run and run, needing minimal maintenance.

Our View

Highly effective mixing units that get the job done with minimal fuss, the VH range are low noise machines that mix to a very demanding standard and offer efficiency, reliability and consistent results. Easy to fill, clean and maintain, these mixing machines are a deservedly popular choice for a broad spectrum of industries.

Technical Specifications

Model	VH 8	VH 14	VH 100	VH 200	VH 300	VH 500
Barrel Capacity	8L / 0.28 ft³	14L / 0.49 ft³	100L / 3.5 ft³	200L / 7.06 ft³	300L / 10.59 ft³	500L / 17.65 ft³
Approximate Working Capacity (weight)	2.5kg / 5.5lbs	4kg / 9lbs	28kg / 62lbs	55kg / 121lbs	80kg / 175lbs	140kg / 308lbs
Approximate Working Capacity (volume)	3.2 - 4.8L / 0.11 - 0.17 ft³	5.6 - 8.4L / 0.2 - 0.3 ft³	40 - 60L / 1.4 - 2.1 ft³	80 - 120L / 2.8 - 4.2 ft³	120 - 180L / 4.2 - 6.3 ft³	200 - 300L / 7 - 10.5 ft³
Agitation Speed (r/min)	24	20	15	12	12	12
Average Mixing Time (min)	6-8	6-8	6-8	6-8	6-10	6-10
USA Power	0.25kW, 1 Phase, 110v	0.37kW, 1 Phase, 110v	1.1kW, 3 Phase, 220v	1.5kW, 3 Phase, 220v	1.5kW, 3 Phase, 220v	2.2kW, 3 Phase, 220v
UK Power	0.25kW, 1 Phase, 240v	0.37kW, 1 Phase, 240v	1.1kW, 3 Phase, 440v	1.5kW, 3 Phase, 440v	1.5kW, 3 Phase, 440v	2.2kW, 3 Phase, 440v
Dimensions (mm)	600 X500 X 500	900 X 380 X 900	1900 x 800 x 1190	2400 x 950 x 1510	2100 x 650 x 1850	2550 x 1000 x 1950
Machine Weight	75kg / 165lbs	83kg / 182lbs	200kg / 440lbs	300kg / 661lbs	350kg / 771lbs	550kg / 1,212lbs
Net Weight (kg)	44
